Description
AM41L button load cell can measure the tension force, It is made of stainless steel, with strong anti-eccentric load capability and double sealing, which is suitable for the detection of force values in various harsh environments.
AM41L button load cell can measure the tension force, It is made of stainless steel,
| Accuracy | 0.03～0.05%F·S |
|---|---|
| Capacity | 3，5，10，20，30，50，100,150，200，300 (kN) |
| Certificate | RoHS, CE |
| Creep | ±0.03 %F·S/30min |
| Material | Stainless steel |
| Sensitivity | 2.0 mV/V |
AM41L button load cell can measure the tension force, It is made of stainless steel, with strong anti-eccentric load capability and double sealing, which is suitable for the detection of force values in various harsh environments.
| Accuracy | 0.03～0.05%F·S |
|---|---|
| Capacity | 3，5，10，20，30，50，100,150，200，300 (kN) |
| Certificate | RoHS, CE |
| Creep | ±0.03 %F·S/30min |
| Material | Stainless steel |
| Sensitivity | 2.0 mV/V |
Contact us if you need the Datasheet PDF.
