AM34c micro load cell weight range is from 1kg to 50 kg；the accuracy is 0.05 %F·S；The size is 58×12.7×12.7 mm；the cable is Φ0.8x100mm.
| Accuracy | 0.05 %F·S |
|---|---|
| Capacity | 1kg-50 kg |
| Certificate | RoHS, CE |
| Creep | ±0.05 %F·S/3min |
| Material | Aluminum alloy |
| Model | AM34C |
| Sensitivity | 1.0 ± 0.15 mv/V |
| Size | 58×12.7×12.7 mm |
AM34c micro load cell weight range is from 1kg to 50 kg；the accuracy is 0.05 %F·S；The size is 58×12.7×12.7 mm；the cable is Φ0.8x100mm.
the load cell is hot sales for Kitchen scale, body scale, baby scale, platform scale, pricing scale, force test equipment.
| Accuracy | 0.05 %F·S |
|---|---|
| Capacity | 1kg-50 kg |
| Certificate | RoHS, CE |
| Creep | ±0.05 %F·S/3min |
| Material | Aluminum alloy |
| Model | AM34C |
| Sensitivity | 1.0 ± 0.15 mv/V |
| Size | 58×12.7×12.7 mm |
Contact us if you need the Datasheet PDF.
